TW Spray Master 250A AIR-COOLED MIG GUN
Rating: 250A CO2/220A Mixed Gases
Duty Cycle: 80%
Wire Size: .025”-.045”(0.6-1.2mm)
T WECO Spray Master 250A AIR-COOLED MIG WELDING TORCH |
|
Type |
10ft(3.0m) |
12ft(3.5m) |
15ft(4.5m) |
|
TW Spray Master 250 MIG Gun Tweco Connector |
TWMS210-3545 |
TWMS212-3545 |
TWMS215-3545 |
|
TW Spray Master 250 MIG Gun Miller Connector |
TWMS210M-3545 |
TWMS212M-3545 |
TWMS215M-3545 |
|
TW Spray Master 250 MIG Gun Lincoln Connector |
TWMS210L-3545 |
TWMS212L-3545 |
TWMS215L-3545 |
|
TW Spray Master 250 MIG Gun Euro Connector |
TWMS210X-3545 |
TWMS212X-3545 |
TWMS215X-3545 |
|
|
|
|
|
No. |
Description |
Order |
|
|
A |
Nozzle 3/8” 9.5mm |
HD22-37 |
|
|
|
Nozzle 1/2” 12.7mm |
HD22-50 |
|
|
|
Nozzle 1/2” 12.7mm |
HD22-50F |
|
|
|
Nozzle 5/8” 15.9mm |
HD22-62 |
|
|
|
Nozzle 5/8” 15.9mm |
HD22-62F |
|
|
B |
Contact Tip .023” 0.6mm |
11-23 |
|
|
|
Contact Tip .030” 0.8mm |
11-30 |
|
|
|
Contact Tip .035” 0.9mm |
11-35 |
|
|
|
Contact Tip .040” 1.0mm |
11-40 |
|
|
|
Contact Tip .045” 1.2mm |
11-45 |
|
|
C |
Gas Diffuser |
HD52-11 |
|
|
D |
Nozzle Insulator |
63J-3 |
|
|
E |
Liner for .030”-.035” (0.8-0.9mm) 15ft (4.6m) |
42-3035-15 |
|
|
|
Liner for .030”-.035” (0.8-0.9mm) 25ft (7.6m) |
42-3035-25 |
|
|
|
Liner for .040”-.045” (1.0-1.2mm) 15ft (4.6m) |
42-4045-15 |
|
|
|
Liner for .040”-.045” (1.0-1.2mm) 25ft (7.6m) |
42-4045-25 |
|
|
|
Liner for .052”-1/16” (1.3-1.6mm) 15ft (4.6m) |
42-116-15 |
|
|
|
|
|
|
|
No. |
Description |
Order |
|
|
1 |
Gun Tube 45° |
LMS63-45 |
|
|
|
Gun Tube 60° |
MS63-60 |
|
|
2 |
Front Handle |
MS84 |
|
|
3 |
Trigger Blade Assembly |
ELC94-BL |
|
|
4 |
Trigger (Standard) |
ELC94 |
|
|
5 |
Front Strain Relief Spring & Cap |
MS144 |
|
|
6 |
Cable Assembly |
TWMS250 |
|
|
7 |
Rear Strain Relief Spring |
235RSSR |
|
|
8 |
Rear Case (Direct Plug) |
R6RC |
|
|
9 |
Control Wire (Tweco/Miller) |
MAK-354 |
|
|
9-1 |
Control Wire (Lincoln) |
LAK-354 |
|
|
10 |
Tweco Central Connector |
350-174H |
|
|
11 |
Miller Central Connector |
350-174MH |
|
|
12 |
Lincoln Central Connector |
350-174LH |
|
|
12-1 |
Gas Tube |
LKGAS |
|
|
13 |
Euro Central Connector |
174EX-1 |
|
|
13-1 |
Cable Ball Joint & Support Spring Big |
400.1010B |
|
|
13-2 |
Euro Rear Handle |
501.2248 |
|
|
13-3 |
Euro Nut |
174X-2 |
|
|
13-4 |
Euro Body Assembly |
174EX-1 |
|
|
13-5 |
Euro Conduit Cap |
174EX-1C |
|
|
TWECO Spray Master 250A AIR-COOLED MIG TORCH AND WELDING CONSUMABLES SHOW: |
TWECO Spray Master 250A AIR-COOLED MIG GUN PACKING: |
.1pc packing in small box, then 5pc packing one carton.
. 135pc packing one pallet.
